Brightness (ANSI lumens) 4000
Resolution XGA (1024x768)
Native Aspect Ratio 4:3
Contrast Ratio (FOFO) 20,000:1
Display Color 30-bit (1.07 billion colors)
Light Source Lamp
Light Source Life a. Normal 6000 hrs, c. SmartEco 10000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
Throw Ratio 1.96~2.15
Zoom Ratio 1.1x
Lens F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm
Projection Offset (Full-Height) 110%
Keystone Adjustment 1D, (Auto) Vertical ± 40 degrees
Picture Modes 3D, Bright, Infographic, Presentation, Spreadsheet, sRGB, User 1, User 2
Resolution Support VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
Horizontal Frequency 15K~102KHz
PC in (D-sub 15pin) (x1)
Monitor out (D-sub 15pin) (x1)
Composite Video in (RCA) (x1)
S-Video in (Mini DIN 4pin) (x1)
HDMI in (x2), HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)
USB Type A (x1)
USB Type Mini B (x1)
RS232 in (DB-9pin)(x1)
Audio in (3.5mm Mini Jack)(x1)
Audio out (3.5mm Mini Jack)(x1)
Operating Temperature 0~40℃
Power Supply AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V) 260W/110V
Acoustic Noise (Typ./Eco.)(dB) 34/29
Remote Control w/ Battery RCX016
Power Cord (by region) x1 (1.8M)
VGA(D-sub 15pin) Cable 1 (1.5m)
3D Glasses
DGD5, (Optional)
Quick Start Guide (x1) 21L
Dimensions (WxHxD) (mm) 296 x120 x221
Net Weight (kg) 2.3
